Frame / Impeller: Plastic
Lead Wire: AWG#24 or Equivalent (+)Red, (-)Black
Ball Bearing 50,000Hrs(40°C)
Sleeve Bearing 30,000Hrs(40°C)
Operating temperature: -10°C~+70°C
Storage temperature: -40°C~+70°C
Model Number | # Bearing Type | Rated Voltage (VDC) | Operating Voltage (VDC) | Input Current (A) | Input Power (W) | Speed (RPM) | Max Air Volum | Max Static Pressure | Noise (dB-A | Weight (g) | ||
(CFM) | m³/min | Inch-H2O | Pa | |||||||||
DC8025#12M | B.S | 12 | 7.0~13.8 | 0.16 | 1.92 | 3000 | 35.31 | 1.13 | 0.14 | 34.81 | 31.0 | 58.0 |
DC8025#24H | B.S | 24 | 14.0~27.6 | 0.14 | 3.36 | 3600 | 42.02 | 1.43 | 0.22 | 54.82 | 36.0 | 58.0 |
DC8025#24M | B.S | 24 | 14.0~27.6 | 0.07 | 1.68 | 3000 | 35.31 | 1.13 | 0.14 | 34.81 | 31.0 | 58.0 |
DC8025#48H | B.S | 48 | 28.0~56.0 | 0.08 | 3.84 | 3250 | 37.43 | 1.43 | 0.22 | 54.82 | 3.60 | 58.0 |
DC8025#48M | B.S | 48 | 28.0~56.0 | 0.07 | 3.36 | 3000 | 35.31 | 1.13 | 0.14 | 34.81 | 31.0 | 58.0 |
