Design compatto
Fissaggio con viti
Lunga durata
Interruzione di sicurezza temperatura
Il termoventilatore compatto previene la formazione di condensa e gelo. Il ventilatore assiale integrato ad alte prestazioni garantisce una temperatura dell'aria interna distribuita uniformemente negli armadi con componenti elettrici/elettronici.
NTL 1500-S | |
Operating voltage | 230VAC or 120VAC |
Heating element | PTC resistor-temperature limiting |
Temperature safety cut-out | to protect against overheating in case of fan failure, automatic reset |
Heater body | anodised extruded aluminium profile |
Surface temperature | max.+75℃(1500W) |
Axial fan, ball bearing | Airflow, free flow 45m³/h (50Hz) or 54m³/h (60Hz) service life 50,000h at +25°C (+77°F) |
Connection | internal connection terminal 1.5mm² with strain relief, clamping torque 0.8Nm max. |
Connection casing | plastic according to UL94 V-0, black |
Mounting | screw fixing |
Fitting position | vertical airflow (air outlet up) |
Operating/Storage temperature | -45 to +70℃ (-49 to +158℉) |
Operating/Storage humidity | max.90% RH(non-condensing) |
Protection type/Protection class | IP20/I(earthed) |
Note | other voltages on request |
Art No.(230V) | Art No.(120V) | Heating capacity¹ | Dimensions | Weight(approx.) |
1500S01 | 1500S10 | 200W | 108x90x124mm | 0.99kg |
1500S02 | 1500S11 | 250W | 108x90x124mm | 0.99kg |
1500S03 | 1500S12 | 300W | 108x90x124mm | 0.99kg |
1500S04 | 1500S13 | 400W | 108x90x124mm | 0.99kg |
1500S05 | 1500S14 | 750W | 108x90x124mm | 0.99kg |
1500S06 | 1500S15 | 950W | 108x90x165mm | 1.60kg |
1500S07 | 1500S16 | 1000W | 108x90x165mm | 1.60kg |
1500S08 | 1500S17 | 1200W | 108x90x165mm | 1.60kg |
1500S09 | 1500S18 | 1500W | 108x90x165mm | 1.60kg |
